3D modeling plug-ins for planning mechanical, electrical and industrial designs in engineering software such as Intergraph, Aveva, Autodesk, and Bentley

  • Graphic card requirement: OpenGL 3.0 support
  • System requirements: As per Host System
  • Minimum required disc space: 1024 MB

Choose options

Licensing
  • After sign up you will get further instructions including software download link sent out per your registered email.
Pack size
  • 1 pc
Product options
Quantity
Packs
Total Pieces
1
You can not see your company prices

Please Log in or register to see your company prices.

From $0.00

Technical Data

Graphic card requirement
OpenGL 3.0 support
System requirements
As per Host System
Minimum required disc space
1024 MB
Security and authorizations
Hilti signed software
Supported operating system
Windows 7

Features & Applications

Features

  • Seamless integration with industry-standard engineering software
  • Built-in intelligence to reduce errors
  • Customizable fabrication drawings and automatically generated Bills of Material
  • Expert support available every step of the way

Applications

  • Integrate our plug-ins with your daily software (Intergraph Smart3D®, Aveva PDMS®, Aveva Everything3D®, Bentley MicroStation®, Bentley OpenPlant®, and Autodesk Plant3D®) and gain access to the entire Hilti digital catalog so you can create digital twins of your assets
  • Deliver faster and more flexible designs through smart features such as: pre-built templates and typicals for faster modeling, design wizards for quickly selecting elements and performing tasks correctly, and flexible solutions to perform freeform designs (limited to some solutions)
  • Reduce errors with built-in filters, rules, and validations to ensure build-ready final designs that are up to specification
  • Deliver accurate fabrication drawings customized to meet construction team specifications and detailed BOM lists that even include items outside the 3D model (eg. Fasteners)
  • Minimize downtime with the help of our plant design experts who will provide plug-in installations and upkeep, consultations on best solutions with your administrators, relevant portfolio library setup, troubleshooting, training services, and bespoke assemblies at a nominal fee for project libraries
