HIT-Glass Positioning aid

Configurator
Documents
Features & Applications
Related Products
Still life picture of HIT Glass Centralizer roll
Still life picture HIT Glass flyer
Glass balustrade installation with HIT Glass. Cropped application image of cutting of EP foam positioning aid to desired length for application needs.
Glass balustrade installation with HIT Glass. Cropped image of removal of tape on EP foam positioning aid prior to adhering it to the glass pane.
Glass balustrade installation with HIT Glass. Cropped application image of glass pane with EP foam positioning aids in the foreground with fully-installed glass balustrade in the background.

Foam positioning aid to center and align glass panes in the metal shoe, for use with the HIT-HY 270 adhesive anchor

Customers also searched for Glass, Glazing, Foam Spool, Balustrade or Handrail.

Choose options

Thickness
  • 0.37 in
Pack size
  • 1 pc
  • 500 pc
 Product options
Quantity
Packs
Total Pieces
1
You cannot see your company prices

Please log in or register to see your company prices.

Discounted net
From $715.00

Documents

Technical information
Documentation
Operating Instruction
pdf PDS_Hilti HIT-GLASS, English [ 755.6 KB ]

Features & Applications

Features

  • Faster glass pane alignment – the positioning aid quickly aligns and holds glass panes securely in the metal profile, enabling easier injection of HIT-HY 270 mortar
  • Greater flexibility – available as a continuous profile, allowing you to cut the foam to your desired length to adapt to your specific application needs
  • Multiple sizes available – foam available in two thicknesses, helping you accommodate the gap between the glass pane and metal profile

Applications

  • Ideal for serial installation of glass panels into metal shoes
  • Fastening glass panes for internal and external glass balustrades and handrails
  • Fastening glass panes on curved and vertically inclined surfaces (up to 35°) in glass balustrade applications

For approval or certificate information, please see individual items.
