Kwik-X CRC Dual Action Anchors

Kwik-X Dual Action Anchor, KHC 3/4" LARGE capsule with KH-EZ 3/4" x 8" screw anchor
Selector for Kwik-X
Hybrid screw anchor anchor setting application.
Kwik-X - drilling for baseplate application using the Safeset method, cropped version.
Kwik-X - dropping in the capsule in a ledger angle application. (US hard hat), cropped version
Kwik-X - driving in the screw anchor using a SIW 6-22 in a ledger angle application. (US hard hat), cropped version
Kwik-X Dual Action Anchor, KHC 3/4" LARGE capsule with KH-EZ 3/4" x 8" screw anchor
Selector for Kwik-X
Hybrid screw anchor anchor setting application.
Kwik-X - drilling for baseplate application using the Safeset method, cropped version.
Kwik-X - dropping in the capsule in a ledger angle application. (US hard hat), cropped version
Kwik-X - driving in the screw anchor using a SIW 6-22 in a ledger angle application. (US hard hat), cropped version

Dual Action Anchor System includes mechanically galvanized KH-EZ CRC screw anchors and KHC adhesive capsules. For fastening in concrete with performance of adhesive anchors and installation speed and simplicity of screw anchors

  • Base material temperature at installation - range: -18 - 104 °F
  • Tested/approved for diamond drilling: Yes, with DD 30-W
  • SAFEset: Yes

Choose options

Anchor size - D
  • 3/8"
  • 1/2"
  • 5/8"
  • 3/4"
​Embedment depth
  • ≤ 3 in
  • > 3 in
  • ≤ 4-1/4 in
  • > 4-1/4 in
  • ≤ 4-1/2 in
  • > 4-1/2 in
Screw length L
  • 3 in
  • 4 in
  • 5 in
  • 5-1/2 in
  • 6 in
  • 6-1/2 in
  • 7 in
  • 8 in
  • 9 in
Return Policy
  • No Returns
Pack size
  • 1 pc
 Product options
Quantity
Packs
Total Pieces
1
You cannot see your company prices

Please log in or register to see your company prices.

Discounted net
From $294.00

Technical Data

Base material temperature at installation - range
-18 - 104 °F
Tested/approved for diamond drilling
Yes, with DD 30-W
SAFEset
Yes
Installation tools
SIW 4AT-22 ½” Cordless impact wrench, SIW 6-22 ½” Cordless impact wrench
In-service temperature – range
-40 - 80 °C
Storage and transportation temperature range
41 - 25 °C
PROFIS Software
Yes

Documents

Features & Applications

Features

  • Unmatched combination of load capacity, productivity and simplicity – new dual-action technology combining the performance of adhesive anchors with the installation speed and simplicity of screw anchors
  • Easier to install – SafeSet method and pre-configured adhesive capsules reduce the number of steps in the installation process and eliminate the need for accessories like brushes, air pumps and dispensers
  • Up to 4x faster installation than injectable mortars – significantly reduce labor costs due to faster, easier setting with an impact driver, and possibility of immediate loading
  • KH-EZ CRC coating meets ASTM B695 Class 55 for added corrosion resistance
  • Extensive technical data including ESR for concrete, seismic category A-F – maximum application coverage and design flexibility fully supported by the PROFIS Engineering software suite

Applications

  • The Kwik-X CRC Dual Action anchor comprises the KHC adhesive capsule and the mechanically galvanized KH-EZ CRC screw anchor for high-performance anchoring of steel to concrete
  • Fastening structural and non-structural steel baseplates to concrete where additional corrosion protection is needed
  • Industrial fastenings – racking, machinery and other equipment

For approval or certificate information, please see individual items.
