DD 110-U-22 Cordless core drill

Configurator
Technical Data
Documents
Features & Applications
Related Products
Services
Still life picture of the cordless core drill DD 110-U-22 with battery B 22-255.
3D still life picture of the cordless core drill DD 110-U-22. Screen display view.
Cropped application picture of the cordless core drill DD 110-U-22 with socket cutter and attached to the cordless vacuum cleaner VC 4X-22. Hand-held dry coring in masonry.
Cropped application picture of the cordless core drill DD 110-U-22 with the SPX A speed core bit and attached to the cordless vacuum cleaner VC 4X-22. Hand-held dry coring in masonry.
Cropped application picture of the cordless core drill DD 110-U-22 with the SPX A speed core bit and attached to the water pump DWP 15-22. Rig-based wet coring in concrete.
Cropped application picture of the cordless core drill DD 110-U-22 with the SPX A speed core bit and attached to the water pump DWP 15-22. Rig-based wet coring in concrete.
Cropped application picture of the cordless core drill DD 150-U-22 with the SPX A speed core bit. Hand-held wet coring in concrete.

Cordless and compact diamond coring machine for handheld or rig-based coring from 12-132 mm (5/16 - 5-1/4") in diameter (Nuron battery platform)

  • Diameter range: 15/32 - 5-3/16 in
  • Base material: Masonry, Asphalt, Concrete, Reinforced concrete
  • Operation mode: Hand-held and rig-mounted drilling system

Customers also searched for battery drill, cordless core drill, Concrete Coring, Diamond Core Drill or Core Drill.

Choose options

Pack size
  • 1 pc
 Product options
Quantity
Packs
Total Pieces
1
You cannot see your company prices

Please log in or register to see your company prices.

Discounted net
From $2,760.00

Technical Data

Diameter range
15/32 - 5-3/16 in
Base material
Masonry, Asphalt, Concrete, Reinforced concrete
Operation mode
Hand-held and rig-mounted drilling system
Rated input power
1650 W
Number of gears
24
Weight according EPTA-Procedure 01/2003 without battery
16.3 lb
Weight of complete system
42 lb
A-weighted emission sound pressure level
101 dB (A) 1
Corner accessibility
4.7 in
  1. According to the applicable product standard (see the Operating Instruction for more details)

Documents

Material safety datasheet
Operating Instruction
Battery Recycling Information
pdf Material safety datasheet Diamond impregnated inserts (g (EN) [ 337 KB ]
pdf Material safety datasheet Diamond impregnated inserts (g (FR) [ 349.1 KB ]
pdf Material safety datasheet LI-ION-BATTERIES >100Wh (EN) [ 357.5 KB ]
pdf Material safety datasheet LI-ION-BATTERIES >100Wh (FR) [ 362.9 KB ]

Features & Applications

Features

  • Compact and versatile – handheld or rig-based coring is now cordless for even easier handling and mobility
  • E-gears for higher performance – electronic gears set RPM/torque combinations for optimized drilling speeds at every diameter
  • Safer handheld coring – Active Torque Control (ATC) helps protect you from uncontrolled spinning if the core bit jams
  • More coring per charge – pair with new cordless optimized core bits for up to 30% more battery reach
  • Easier core removal – oscillating function helps shake loose stuck concrete cores to save downtime

Applications

  • Rig-based wet drilling in concrete for pipe penetrations, cable trays and ducts and for the installation of railings and barriers
  • Handheld wet drilling for setting large-diameter anchors and reinforcing bars
  • Handheld dry drilling in masonry for pipe penetrations in plumbing, heating and air conditioning installations

For approval or certificate information, please see individual items.

Services

Hilti Tool Service

  • 1 or free, in and out of the repair center the same day or repair is free of charge
  • Service is free of charge up to 2 years, including wear & tear, pick-up and delivery
  • After 2 years repair costs are capped
  • Product warranty against parts and manufacturing irregularities for 20 years
More information about Tool Services

Fleet Management

  • Monthly usage fee covering all tool, service and repair costs helping to ensure absolute cost control and back-office efficiency.
  • Loan tools during repair to reduce downtime.
  • Temporary tools for peak times and special applications help to reduce investments.
  • Theft coverage helps to reduce financial risk and unexpected expenses.
More information about Fleet Management

LifeTime Services

  • 2 years no repair costs from date of purchase, including wear & tear parts, shipping and labor
  • After every repair again 3-month no-repair-cost period
More information about LifeTime Services
