DD 160-22 Cordless core drill

Configurator
Technical Data
Documents
Features & Applications
Related Products
Services
Still life picture of the cordless core drill DD 160-22.
3D still life picture of the cordless core drill DD 160-22. Screen display view.
Cropped application image of rig based wet coring using WMS 100-20 and DD 150-U-22.
Cropped application image of rig based wet coring using WMS 100-20 and DD 160-22.
Cropped application image of rig based wet coring using WMS 100-20 and DD 160-22.
Cropped application picture of the cordless core drill DD 160-22 with the SPX A speed core bit and attached to the drill stand and the water pump DWP 15-22. Rig-based wet coring in concrete.
Cropped application picture of the cordless core drill DD 160-22 with the SPX A speed core bit and attached to the drill stand and the water pump DWP 15-22. Rig-based wet coring in concrete.

Compact and powerful cordless coring machine for rig-based diamond coring from 52-162 mm (2 - 6-3/8") in diameter (Nuron battery platform)

  • Diameter range: 1-31/32 - 6-3/8 in
  • Base material: Asphalt, Concrete, Reinforced concrete
  • Operation mode: Rig-based drilling system

Choose options

Pack size
  • 1 pc
 Product options
Quantity
Packs
Total Pieces
1
You cannot see your company prices

Please log in or register to see your company prices.

Discounted net
From $2,250.00

Technical Data

Diameter range
1-31/32 - 6-3/8 in
Base material
Asphalt, Concrete, Reinforced concrete
Operation mode
Rig-based drilling system
Rated input power
1650 W
Weight according EPTA-Procedure 01/2003 without battery
15 lb
Weight of complete system
41 lb
A-weighted emission sound pressure level
87 dB (A) 1
Corner accessibility
4 in
  1. According to the applicable product standard (see the Operating Instruction for more details)

Documents

Material safety datasheet
Operating Instruction
pdf Material safety datasheet Diamond impregnated inserts (g (EN) [ 337 KB ]
pdf Material safety datasheet Diamond impregnated inserts (g (FR) [ 349.1 KB ]

Features & Applications

Features

  • Compact and easy to handle – our user-friendly core drill for rig-based coring is now cordless for even easier handling and mobility
  • E-gears for higher performance – electronic gears set RPM/torque combinations for optimized drilling speeds at every diameter
  • Multiple drill stand options – combine with our high-grade drill stand for many useful features or our compact drill stand for standard functions
  • More coring per charge – pair with new cordless optimized core bits for up to 30% more battery reach
  • Easier core removal – oscillating function helps shake loose stuck concrete cores to save downtime

Applications

  • Rig-based wet drilling in concrete for pipe penetrations in plumbing, heating and air conditioning installations
  • Rig-based wet drilling for small pipe penetrations in plumbing applications
  • Stitch drilling for cable trays and ventilation ducts

For approval or certificate information, please see individual items.

Services

Hilti Tool Service

  • 1 or free, in and out of the repair center the same day or repair is free of charge
  • Service is free of charge up to 2 years, including wear & tear, pick-up and delivery
  • After 2 years repair costs are capped
  • Product warranty against parts and manufacturing irregularities for 20 years
  • No registration or proof of purchase ever required
More information about Tool Services

Fleet Management

  • Monthly usage fee covering all tool, service and repair costs helping to ensure absolute cost control and back-office efficiency.
  • High-performing tools and latest technology help to increase jobsite productivity.
  • Loan tools during repair to reduce downtime.
  • Temporary tools for peak times and special applications help to reduce investments.
  • Theft coverage helps to reduce financial risk and unexpected expenses.
More information about Fleet Management

LifeTime Services

  • 2 years no repair costs from date of purchase, including wear & tear parts, shipping and labor
More information about LifeTime Services
