Nuron

SM 60-22 Cordless miter saw

Cordl. miter saw SM 60-22 box #2390415

Configurator
Technical Data
Documents
Features & Applications
Related Products
Services
Still life picture of the miter saw SM 60-22 with dust bag and circular saw blade.
Application picture of the cordless mitter saw SM 60-22. Wood cutting application.
Cropped image of application picture of the cordless miter saw SM 60-22 attached to the cordless vacuum cleaner VC 4X-22. Wood cutting application. Application without gloves.
Application picture of the cordless mitter saw SM 60-22. Cutting aluminum.
Application picture of the cordless mitter saw SM 60-22. Wood cutting application. Compound cut.
Cropped image of application picture of the cordless miter saw SM 60-22 attached to the cordless vacuum cleaner VC 4X-22. Wood cutting application. Application without gloves.
Cropped application picture of a worker is using a SM 60-22 on an interior wood jobsite to cut a wood plank disclaimer: this picture is without glove due to German rotative tool law
Cropped application picture of a worker is using a SM 60-22 on an interior wood jobsite to cut a wood plank disclaimer: this picture is without glove due to German rotative tool law
A man worker is using the SM 60-22 with a VC 4MX-22 & T15 on an interior wood jobsite to cut a wood plank disclaimer: this picture is without glove due to German rotative tool law

Dual-bevel sliding compound miter saw with a cross cut capacity up to 100x355mm│4”x 13-3/4" (Nuron battery platform)

  • Blade diameter: 12 in
  • Base material: Wood, Plastic
  • No load RPM: gear 1: 4300 rpm

Customers also searched for Miter Saw, Chop Saw, Compound Miter Saw or Wood Saw.

Customize your kit

Tool Body
Tool body with cardboard box Includes: 1x Clamp SM 60-22, 1x Circ. saw blade SCBW WU SPX 12”, 1x Dust bag SM 60-22
How many kits do you want to order?
You cannot see your company prices

Please log in or register to see your company prices.

Discounted net
$1,369.00

Technical Data

Blade diameter
12 in
Base material
Wood, Plastic
No load RPM
gear 1: 4300 rpm
Guiding rail compatibility
No
Max. bevel angle
48 °
Max. miter angle
60 °

Documents

pdf Operating Instruction SM 60-22 (01), English, Spanish, French, Portuguese [ 6.5 MB ]

Features & Applications

Features

  • Precision cutting – miter (≤ 60° right ≤ 52° left) and bevel (up to 48°) adjusts in both directions for smooth compound cuts and accurate straight cuts throughout the saw’s lifetime
  • Variable speed control – 6 speeds (2000-4300 RPM) allow you to match blade speed with material to optimize cutting quality, performance and battery life when paired with our blades
  • Ergonomic and efficient – forward-sliding rail saves space while front-facing bevel adjustments help streamline your workflow
  • Integrated LED shadow line – line up your workpiece for faster and more accurate cuts, even in low-light conditions
  • Safer and cleaner – fast blade brake and effective dust removal for a safer and cleaner working environment

Applications

  • Commercial wood framing, especially precise, serial cuts in beams, structural elements and temporary supports
  • Clean cuts for concrete formwork such as tilt walls and architectural concrete
  • Bevel and miter cuts for case work, mill work and interior woodwork such as cabinets, molding and trim
  • Cutting aluminum extrusions on-site for building envelope applications
  • Straight cuts in PVC, ABS, and occasional cuts in aluminum and conduit for flush connections in plumbing and electrical installations

Services

Fleet Management

  • Monthly usage fee covering all tool, service and repair costs helping to ensure absolute cost control and back-office efficiency.
  • Theft coverage helps to reduce financial risk and unexpected expenses.
More information about Fleet Management

LifeTime Services

  • 2 years no repair costs from date of purchase, including wear & tear parts, shipping and labor
More information about LifeTime Services
