KHC Kwik-X Capsule
Ultimate-performance adhesive capsule for Kwik-X Dual Action Anchor System for fastenings in concrete. In combination with KH-EZ screw anchors (sold separately) offers adhesive anchor performance with the installation speed of screw anchors.
- Approvals / Test reports: ICC-ES report (concrete), Seismic
- Base materials: Concrete (cracked), Concrete (uncracked)
- Base material condition (as per approval): Dry, Wet
Customers also searched for adhesive screw anchor, screw adhesive anchor, SafeSet anchor, industrial fastening anchor or baseplate anchor.
Technical Data
Approvals / Test reports
ICC-ES report (concrete), Seismic
Base materials
Concrete (cracked), Concrete (uncracked)
Base material condition (as per approval)
Dry, Wet
Base material temperature at installation - range
-18 - 104 °F
Type of fixing
Through-fastening
Installation direction
All
Tested/approved for diamond drilling
Yes, with DD 30-W
SAFEset
Yes
Cleaning procedures
Automatic Cleaning (SafeSet Hollow Drill Bit), Compressed-Air Cleaning, Non Cleaning
Installation tools
SIW 4AT-22 ½” Cordless impact wrench, SIW 6-22 ½” Cordless impact wrench
Removable
Yes
In-service temperature – range
-40 - 80 °C
Storage and transportation temperature range
5 - 25 °C
PROFIS Software
Yes
IBC compliance
IBC 2015, IBC 2018, IBC 2021
Documents
Features & Applications
Features
- Unmatched combination of load capacity, productivity and simplicity – new dual-action technology combining the performance of adhesive anchors with the installation speed and simplicity of screw anchors
- Easier to install – SafeSet method and pre-configured adhesive capsules reduce the number of steps in the installation process and eliminate the need for accessories like brushes, air pumps and dispensers
- Up to 4x faster installation than injectable mortars – significantly reduce labor costs due to faster, easier setting with an impact driver, and possibility of immediate loading
- Extensive technical data including ESR for concrete, seismic category A-F – maximum application coverage and design flexibility fully supported by the PROFIS Engineering software suite
Applications
- The Kwik-X Dual Action anchor comprises the KHC adhesive capsule and the KH-EZ screw anchor (please order separately) for high-performance anchoring of steel to concrete
- Fastening structural and non-structural steel baseplates to concrete
- Industrial fastenings – racking, machinery and other equipment
For approval or certificate information, please see individual items.
