CFS-BTS Firestop Bottom Track Seal
New product
Ultimate
Item #r17169026
Preformed firestop solution for bottom-of-wall drywall joints – increases productivity at the jobsite and eliminates the need for slow, messy sealants
- Length: 72 in
- LEED VOC: 1 g/l
- Approvals: UL 2079
Share
Features & Applications
Features & Applications
Features
- Easier to install under real jobsite conditions, compressible firestop joint seal suitable for installation in temperatures as low as 14°F
- Higher productivity – the preformed firestop replaces 5/8” shims and works with kick-lifts to help save time and improve quality control of drywall install
- Simpler inspections – may not be subject to destructive testing to prove sealant depth
- Sound and Leakage-rated joint seal – CFS-BTS firestop can provide STC ratings for fire/sound walls, and has been tested in accordance with L-rating compliance in smoke barrier walls (IBC)
- Compliance with the most stringent LEED green building regulations – provides industry-leading low VOC, LEED 4.1, and Red List (LBC) compliance
Applications
- Firestop, smoke and sound seal for the bottom-of-the-wall joints between bottom track and drywall on flat concrete slabs
- Tested and UL listed with standard 1-hour and 2-hour partition walls, resilient channel walls and shaft walls. (5/8” and 1-¼" available)
For approval or certificate information, please see individual items.
Technical Data
Documents & Videos
Consulting & Support
BOTTOM-OF-WALL FIRESTOP IN 4 EASY STEPS
Step 1
Clean surface
Step 2
Reveal adhesive
Step 3
Adhere to track
Step 4
Set drywall board
INCREASE FIRESTOP INSTALLATION SPEED AND ACCURACY
CFS-BTS Bottom Track Seal
Achieve jobsite readiness sooner with Hilti’s new bottom-of-wall firestop solution, CFS-BTS Bottom track seal. This preformed firestop solution with XPLE technology helps protect against fire, smoke and sound from bottom track and drywall to flat concrete slabs and metal deck without changing your track layout or framing process.
Using a preformed firestop product can save time and improve the quality control and accuracy of drywall installation without skilled labor. With more cost-efficiency, nearly zero product waste, and simplified inspections, CFS-BTS helps increase productivity on the jobsite and keep your projects on schedule.
