Nuron

TE 5-22 Cordless rotary hammer

Configurator
Technical Data
Documents
Features & Applications
Related Products
Services
TE 5-22 Cordless Rotary Hammer and battery
Formwork concrete drilling with TE 5 - 22 Cordless Rotary Hammer.
Temporary fixing, concrete drilling with TE 5-22 Cordless Rotary Hammer.
Concrete chiseling with TE 5-22 Cordless Rotary Hammer.

Powerful SDS Plus rotary hammer drill with long body and spade grip ideal for downward drilling (Nuron battery platform)

  • Weight according EPTA-Procedure 01/2003 without battery: 6 lb
  • Optimum Hammer drilling range: 1/4 - 23/32 in
  • Single impact energy: 1.8 ft-lbf

Customers also searched for cordless rotary hammer drill, rotary hammer drill, battery rotary hammer drill, Nuron rotary hammer drill or Nuron battery rotary hammer drill.

Choose options

Pack size
  • 1 pc
 Product options
Quantity
Packs
Total Pieces
1
You cannot see your company prices

Please log in or register to see your company prices.

Discounted net
From $289.00

Technical Data

Weight according EPTA-Procedure 01/2003 without battery
6 lb
Optimum Hammer drilling range
1/4 - 23/32 in
Single impact energy
1.8 ft-lbf
Hammer drilling diameter range
5/32 - 1-3/32 in
Hammer drilling RPM
1070 rpm
Full hammering frequency
5220 impacts/minute
Functionality
Active Torque Control (ATC), Chiseling, Chipping, Depth gauge, Removable chuck, Reverse mode, Torque clutch, Working light LED
Triaxial vibration for chiseling into concrete
10.3 m/s² 1
A-weighted emission sound pressure level
98 dB (A) 2
Dust removal system available
TE DRS-D, TE DRS-C, TE DRS-5
  1. According to the applicable product standard (see the Operating Instruction for more details)
  2. According to the applicable product standard (see the Operating Instruction for more details)

Documents

Material safety datasheet
Operating Instruction
Battery Recycling Information
pdf Material safety datasheet Hilti Grease (EN) [ 229.3 KB ]
pdf Material safety datasheet Hilti Grease (FR) [ 238.6 KB ]
pdf Material safety datasheet LI-ION-BATTERIES <100Wh (FR) [ 314.7 KB ]
pdf Material safety datasheet LI-ION-BATTERIES <100Wh (EN) [ 246.2 KB ]

Features & Applications

Features

  • Hilti’s ultimate SDS Plus drill for formwork and baseplates – the long tool body makes the TE 5-22 our most comfortable rotary hammer for drilling downwards
  • Outsized performance – Hilti’s best performance-to-weight ratio in this tool category, with enough power for tough concrete drilling jobs up to 16 mm diameter
  • One-for-all versatility – chipping mode and exchangeable chucks (sold separately) mean you can use this rotary hammer with SDS chisels, hole saws, right-angle chucks and even wood/steel drill bits
  • Practical safety features – equipped with Active Torque Control to help protect against unexpected rotation, and compatible with various dust removal solutions (sold separately)
  • Nuron battery platform – cordless SDS Plus rotary hammer drills without compromise thanks to longer-lasting batteries, high-performance drill bits and a range of services to help you stay productive, today and tomorrow

Applications

  • Drilling and hammer drilling in concrete and masonry, especially in downward-facing working positions
  • Virtually dust-free drilling and chiseling (TE DRS-5 on-board dust removal system with chipping head or TE DRS-C vacuum cleaner connector required)
  • Light-duty chiseling – such as tile scraping, channel cleaning or surface correction
  • Occasional drilling in wood and steel (with optional quick-release chuck)
  • Setting anchors and drop-in anchors (with optional setting tools)

For approval or certificate information, please see individual items.

Services

Hilti Tool Service

  • Product warranty against parts and manufacturing irregularities for 20 years
  • Service is free of charge up to 2 years, including wear & tear, pick-up and delivery
  • 1 or free, in and out of the repair center the same day or repair is free of charge
More information about Tool Services

Fleet Management

  • Monthly usage fee covering all tool, service and repair costs helping to ensure absolute cost control and back-office efficiency.
  • High-performing tools and latest technology help to increase jobsite productivity.
  • Loan tools during repair to reduce downtime.
  • Temporary tools for peak times and special applications help to reduce investments.
  • Theft coverage helps to reduce financial risk and unexpected expenses.
More information about Fleet Management
